As we all know, radar target simulator is expensive in the market, the launch of M series radar target simulator is to provide customers with the highest cost-effective products. M series products are characterized by small size, light weight, low power consumption and high cost performance, which can meet the target simulation performance of different users.

Working frequency band: 76GHz ~ 81GHz
Instantaneous bandwidth: 5GHz
Maximum linear received power (without antenna) : -10dBm
Number of channels: 1
Distance range: 3 to 1000m.
Distance step: 1mm
Speed range: -720~720km/h
Speed step: 0.002m/s
RCS adjustable range: 85dB
RCS step: 0.1dB
Number of simulated targets: 1

Working frequency band: 76GHz ~ 81GHz
Instantaneous bandwidth: 5GHz
Maximum linear received power (without antenna) : -10dBm
Number of channels: 1
Distance range: any combination of 5m, 50m, 100m and 200m, the distance range can be customized between 3 and 1000m.
Distance accuracy: ±0.025m
Speed range: -720~720km/h
Speed step: 0.002m/s
RCS adjustable range: 85dB
RCS step: 0.1dB
Number of simulated targets: 1~4

Working frequency band: 76GHz ~ 81GHz
Instantaneous bandwidth: 2GHz
Maximum linear received power (without antenna) : -10dBm
Number of channels: 1
Distance range: 0 to 1000m
Distance step: 1mm
Speed range: -720~720km/h
Speed step: 0.002m/s
RCS adjustable range: 85dB
RCS step: 0.1dB
Number of simulated targets: 1~2
